GSE++ library: read and write GSE waveform data (prototypes). More...
#include <string>#include <iostream>
Go to the source code of this file.
Classes | |
| class | GSE2::Terror |
| Base class for all exceptions in this module. More... | |
| class | GSE2::waveform::TWID2 |
| A class to hold and manage the WID2-line. This is a struct - because it is a simple collection of fields together with a few formatting functions. More... | |
| class | GSE2::waveform::TSTA2 |
| A class to hold and manage the STA2-line. More... | |
| class | GSE2::waveform::TCHK2 |
| A class for the cumulative calculation of checksums. More... | |
| class | GSE2::waveform::differences::Tapply_diff |
| Elementary operator to calculate differences. More... | |
| class | GSE2::waveform::differences::Tremove_diff |
| Elementary operator to calculate the sum, which removes differences. More... | |
| class | GSE2::waveform::differences::Tdiff_operator< n, OP > |
| Template to apply or remove differences of any order n. More... | |
| class | GSE2::waveform::differences::Tdiff_operator< 0, OP > |
| Template specialization for order zero. More... | |
| class | GSE2::waveform::TDAT2sum |
| Handle checksum and sample count. More... | |
| class | GSE2::waveform::TDAT2read |
| Abstract base class for reading GSE2 waveform data. More... | |
| class | GSE2::waveform::TDAT2write |
| Abstract base class for writing GSE2 waveform data. More... | |
| class | GSE2::waveform::TDAT2readCM6 |
| Derived class for reading CM6 subformat data. More... | |
| class | GSE2::waveform::TDAT2writeCM6 |
| Derived class for writing CM6 subformat data. More... | |
Namespaces | |
| GSE2 | |
| All stuff defined by the GSE2 standard. | |
| GSE2::waveform | |
| All waveform related stuff. | |
| GSE2::waveform::differences | |
| Stuff to apply and remove first, second and higher differences. | |
Macros | |
| #define | TF_GSEXX_H_VERSION "TF_GSEXX_H V1.5" |
| #define | TF_GSEXX_H_CVSID "$Id$" |
Typedefs | |
| typedef int | GSE2::waveform::intT |
| All GSE2 waveform data is based on 4 byte integers. More... | |
| typedef differences::Tdiff_operator< 1, differences::Tapply_diff > | GSE2::waveform::apply1stdiffT |
| Operator to apply first differences. More... | |
| typedef differences::Tdiff_operator< 2, differences::Tapply_diff > | GSE2::waveform::apply2nddiffT |
| Operator to apply second differences. More... | |
| typedef differences::Tdiff_operator< 1, differences::Tremove_diff > | GSE2::waveform::remove1stdiffT |
| Operator to remove first differences. More... | |
| typedef differences::Tdiff_operator< 2, differences::Tremove_diff > | GSE2::waveform::remove2nddiffT |
| Operator to remove second differences. More... | |
Enumerations | |
| enum | GSE2::waveform::Esubformat { GSE2::waveform::SF_INT, GSE2::waveform::SF_CM6, GSE2::waveform::SF_CM8, GSE2::waveform::SF_AUT, GSE2::waveform::SF_AU6, GSE2::waveform::SF_AU8 } |
| Possible subformats of waveform data. More... | |
Functions | |
| template<class C > | |
| bool | GSE2::GSEIDmatch (const std::string &line) |
| Check GSE identifier at beginning of line. More... | |
Detailed Description
GSE++ library: read and write GSE waveform data (prototypes).
$Id$
- Date
- 16/03/2002
GSE++ library: read and write GSE waveform data (prototypes)
Copyright (c) 2002 by Thomas Forbriger (IMG Frankfurt)
libgsexx is free software; you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation; either version 2 of the License, or (at your option) any later version.
This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details.
You should have received a copy of the GNU General Public License along with this program; if not, write to the Free Software Foundation, Inc., 51 Franklin St, Fifth Floor, Boston, MA 02110-1301 USA
REVISIONS and CHANGES
- 16/03/2002 V1.0 Thomas Forbriger
- 26/12/2003 V1.1 final checksum is defined to be absolute value
- 28/04/2006 V1.2 classes that use virtual functions require the definition of an explicit virtual destructor
- 24/07/2006 V1.3 provide milliseconds precision !! interface has changed: field Fseconds is removed from TWID2
- 11/11/2009 V1.4
- abs is not overloaded for int in header cmath- !! interface has changed: Terror now uses string class
- 06/12/2011 V1.5 introduced some code for debugging second differences
Definition in file gsexx.h.
